Processor

Qualcomm 560MHz CPU, MIPS 74Kc

Memory

64MB DDR2 RAM,8MB Flash

Interface

1 1 10/100Mbps Shielded Ethernet Port (LAN/POE)
1 Reset Button

Power Supply

Passive Power over Ethernet via LAN (+4,5pins; -7,8pins)
Voltage range: 16-27VDC

Max. Power Consumption

8.8 W
Note: When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable.

Dimensions ( W x D x H )

366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.)

Antenna Gain

23dBi

Antenna Beamwidth

9°(Azimuth), 7°(Elevation)

Protection

15KV ESD Protection
6KV Lightning Protection

Enclosure

Material: Outdoor PC stabilized plastic
Weatherproof: IP65 water and dust proof design

Wireless Standards

IEEE 802.11a/n

Proprietary Protocol

TDMA Mode (with Pharos MAXtream enabled)

Wireless Speeds

Up to 300Mbps (40MHz,Dynamic)
Up to 144.4Mbps (20MHz,Dynamic)
Up to 72.2Mbps (10MHz,Dynamic)
Up to 36.1Mbps (5MHz,Dynamic)

Frequency

5.15~5.85GHz
Note: Available operating frequency may vary depending on the limitations of the countries or regions in which the device is used.

Transmission Power

Max. 29dBm/790mW (Adjustable power by 1dBm)

Operating Modes

AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP Client)

Network Configuration

WAN: Static/Dynamic/PPPoE/L2TP/PPTP
LAN: Static/Dynamic/DHCP
Forwarding: DMZ/ALG/UPnP/Virtual Server/Port Trigger
Security: SPI Firewall/ Ping Forbidden/VPN/DoS Protection
Access Control
Static Routing
Bandwidth Control
IP & MAC Binding

Wireless Configurations

Pharos MAXtream TDMA Technology
Selectable Channel Width: 5/10/20/40MHz
Auto Channel Selection
Transmit Power Control
Dynamic Frequency Selection(DFS)
WDS Enable/Disable
Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
64/128/152-bit WEP Encryption
SSID Broadcast Enable/Disable
Multi-SSID with VLAN Tagging(AP Mode only)
Distance/ACK Timeout Setting
Wireless MAC Address Filter
Wireless Advanced:
Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia

Management Features

Discovery and Remote Management via Pharos Control application
HTTP/HTTPS Web-based management
System log
SNMP Agent(v2c)
Ping Watch Dog
Dynamic DDNS
SSH Server

System Tools

Indicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory
Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
Spectrum Analyzer
Speed Test
Ping
Traceroute

System-level Optimizations

Optimized IGMP Snooping/Proxy for multicast applications
Hardware watch dog

Dimensions(W x D x H)

85.8×43.9×29.7 mm

Interfaces

1 AC Jack with Earth Ground
1 10/100Mbps Shielded Ethernet Port (Power + Data)
1 10/100Mbps Shielded Ethernet Port (Data)

Button

Remote Reset Button

Power Status LEDs

Green

Input

100-240VAC, 50/60Hz

Output

24VDC, 0.5A Max
+4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)

Efficiency

>84.29%

Certifications

CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark

Certification

CE, FCC, RoHS, IP65

Package Content

Outdoor Wireless CPE
24V 0.5A Passive PoE Adapter
Pole Mounting Straps
AC Power Cord
Installation Guide

System Requirements

Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.

Environment

Operating Temperature: -40℃~70℃ (-40℉~158℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
