Mikrotik RB5009UG+S+IN

The ultimate heavy-duty home lab router with USB 3.0, 1G and 2.5G Ethernet and a 10G SFP+ cage. You can mount four of these new routers in a single 1U rackmount space! Unprecedented processing power in such a small form factor.

Double the usual performance: we took your feedback from the MikroTik User Meetings to create the perfect home lab router: compact, powerful, with multiple powering options and efficient cooling.RB5009 has it all, and even more!

The board features 9 wired ports and a full-sized USB 3.0. Seven of the ports are Gigabit Ethernet, another one is 2.5 Gigabit Ethernet, and the last one is a 10G SFP+ cage. All the ports are connected to a powerful Marvell Amethyst family switch-chip with a 10 Gbps full-duplex line leading to the Marvell Armada Quad-core ARMv8 1.4 GHz CPU. Both CPU and the switch-chip are located on the bottom of the board – so the case acts as a massive heat-sink!

RB5009UG+S+IN can be powered in 3 different ways:

a) PoE-in from Ethernet port #1

b) DC Jack

c) 2-pin terminal on the side

Boards come with 1GB of DDR4 RAM and 1GB NAND storage. This combination of ports and components, compared to our other products in a similar form factor, provides almost double the performance in configurations with heavy CPU loads.

With a simple set of mounting accessories, you can mount FOUR of these routers in a single 1U rackmount space! No more server-room-Tetris, just pure productivity.

Specifications

Details

Product code RB5009UG+S+IN

Architecture ARM 64bit

CPU 88F7040

CPU core count 4

CPU nominal frequency 350-1400 (auto) MHz

Switch chip model 88E6393

RouterOS license 5

Size of RAM 1 GB

Storage size 1 GB

Storage type NAND

MTBF Approximately 200'000 hours at 25C

Tested ambient temperature -40°C to 60°C

IPsec hardware acceleration Yes

Powering

Details

Number of DC inputs 3 (PoE-IN, DC jack, 2-pin terminal)

DC jack input Voltage 24-57 V

2-pin terminal input Voltage 24-57 V

Max power consumption 25 W

Max power consumption without attachments 14 W

Cooling type Passive

PoE in 802.3af/at

PoE in input Voltage 24-57 V

Ethernet

Details

10/100/1000 Ethernet ports 7

Number of 2.5G Ethernet ports 1

Fiber

Details

SFP+ ports 1

Peripherals

Details

Number of USB ports 1

USB Power Reset Yes

USB slot type USB 3.0 type A

Max USB current (A) 1.5
