Mercusys AC10 AC1200 Dual Band Wifi Router

High-Speed Wi-Fi – Stream with fast and stable connections, reaching speeds up to 1167 Mbps (300 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band)

4 High-Gain External Antennas – Receive strong Wi-Fi signals in every corner of your home

Easy Installation – Set up in minutes guided by the MERCUSYS app or an intuitive web UI

Active Parental Controls – Protect your family by setting appropriate access policies for responsible, safe internet use

Multi-Mode — Access Point Mode, Range Extender Mode, and Router Mode supported to satisfy all application scenarios

IPTV and IPv6 Supported

WirelessWireless Standards

IEEE 802.11ac/n/a 5 GHz, IEEE 802.11b/g/n 2.4 GHz

 Frequency

2.4 GHz, 5 GHz

 WiFi Speeds

Up to 300 Mbps on 2.4 GHz, 867 Mbps on 5 GHz

 Reception Sensitivity

11g 6Mbps: -96dBm

11g 54Mbps: -78dBm

11n HT40 MCS7: -74dBm

11n HT20 MCS7: -71dBm

11a 6Mbps: -97dBm

11a 54Mbps: -79dBm

11ac VHT20 MCS8: -74dBm

11ac VHT40 MCS9: -70dBm

11ac VHT80 MCS9: -65dBm

 Transmission Power

2.4 GHz < 20dBm (EIRP)

5 GHz < 23dBm (EIRP)

 Wireless Security

WEP

WPA / WPA2-Personal

WPA2 / WPA3-Personal

 Wireless Functions

Enable/Disable Wireless Radio, WMM

HardwareDimensions

4.5 × 3.7 × 1.0 in (114 × 94 × 26 mm)

 Interfaces

1× 10/100 Mbps WAN Port

2× 10/100 Mbps LAN Ports

 Button

Reset/WPS Button

 External Power Supply

9V/0.85A

 Antenna Type

4× 5 dBi Fixed Omni-Directional Antennas

SoftwareOperation Modes

Router Mode, Access Point Mode

 WAN Type

Dynamic IP/Static IP/PPPoE/L2TP/PPTP

 Management

Access Control, Local Management, Remote Management

 DHCP

Server, DHCP Client List

 NAT Forwarding

Port Forwarding, Port Triggering, UPnP, DMZ

 Firewall Security

SPI Firewall, IP and MAC Address Binding

 Guest Network

2.4 GHz Guest Network, 5 GHz Guest Network

OthersPackage Contents

AC1200 Wireless Dual Band Router AC10

Power Adapter

Quick Installation Guide

RJ45 Ethernet Cable

 Environment

Operating Temperature: 0°C~40°C (32°F~104°F)

Operating Humidity: 10%~90% Non-Condensing

Storage Humidity: 5%~90% Non-Condensing
