Coverage

Up to 2,000 sq. ft.

Interface

WEB: ASUSWRT
APP: ASUS Router APP

Operation mode

Wireless router mode
Access point mode
Media bridge mode

Speed

Up to 3600 Mbps

Wireless Security

AiProtection
VPN
WPS support, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise
WPS
Let's Encrypt
DNS-over-TLS
SSH
Security Scan
Firewall
Maximum Firewall Keyword Filter: 64
Maximum Firewall Network Service Filter: 32
Maximum Firewall URL Filter: 64

Model Name

RT-BE58U

Network Standard

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
WiFi 7 (802.11be)
IPv4
IPv6

Product Segment

BE3600 ultimate BE Performance: 688+2882 Mbps

Data Rate

802.11a: up to 54 Mbps
802.11b: up to 11 Mbps
802.11g: up to 54 Mbps
WiFi 7 (802.11be) (2.4GHz): up to 688 Mbps
WiFi 7 (802.11be) (5GHz): up to 2882 Mbps

Antenna

External antenna x 4

Transmit/Receive

2.4GHz 2x2
5GHz 2x2

Processor

2.0 GHz Quad-Core Processor

Memory

256 MB Flash
1 GB RAM

Boosts speed

OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
4096-QAM high data rate
20/40/80/160 MHz bandwidth

Operating Frequency

2.4GHz / 5GHz
2.4 GHz
5 GHz

Ports

I/O Ports:
1x 2.5G for WAN/LAN
1x 1G for WAN/LAN
3 x 1G LAN
USB 3.2 Gen 1 x 1

Button

WPS Button, Reset Button, Power Button

LED Indicator

Power x 1
WAN x 1
LAN x 1
2.4GHz WiFi x 1
5GHz WiFi x 1

Power Supply

AC Input: 100V~240V (50~60Hz)
DC Output: 12 V with max. 2 A current

Package content

RT-BE58U
RJ-45 cable
Power adapter
Quick Start Guide
Warranty card

Product Weight (g)

461g

AiMesh

AiMesh:
Primary AiMesh Router
AiMesh Node

AiProtection

AiProtection Pro
• Router Security Assessment
• Malicious Site Blocking
• Two-Way IPS
• Infected Device Prevention and Blocking

Parental Control

Allow you to block access to unwanted websites and apps.
Web & Apps Filters
Time Scheduling
Safe Browsing
Customized Internet Schedule

Traffic Control

Adaptive QoS:
Bandwidth Monitor
Bandwidth Limiter

Maximum Bandwidth Limiter Rule: 32
Traditional QoS
Maximum Traditional QoS Rule: 32
Traffic Monitor
Real-time Traffic Monitor
Wired Traffic Monitor
Wireless Traffic Monitor
Traffic Analyzer
Traffic Analysis Period: Daily, Weekly, Monthly
Website History

Dimensions

238 x 193 x 59 mm

Wireless

MU-MIMO
UTF-8 SSID
WiFi MAC Address Filter
• Maximum MAC Filters: 64
Wireless Scheduler
Airtime Fairness
RADIUS Client
Universal Beamforming
Explicit Beamforming

WAN

Internet connection Type: PPPoE, PPTP, L2TP, Automatic IP, Static IP Dual WAN
3G / 4G LTE dongle
4G / 5G Auto Mobile Tethering
Port forwarding

Maximum Port Forwarding Rule: 64
Port triggering

Maximum Port Triggering Rule: 32
DMZ
DDNS

NAT Passthrough: PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay

LAN

DHCP Server
IGMP Snooping
IPTV
Manually Assign IP Address

• Maximum Manually Assign IP Address Rule: 64
Wake on LAN (WOL)

VPN

Instant Guard
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
VPN Server WireGuard

USB application

4G / 5G Auto Mobile Tethering
File System : HFS+, NTFS, vFAT, ext2, ext3, ext4
Safely Remove Disk
AiCloud
Download Master
AiDisk
Media Server
Time Machine
Samba Server
FTP Server
Shared Folder Privileges

Administration

Configuration Backup and Restore
Diagnosis tools
Feedback System
System Log
New Device Connect Notification
Login Captcha
Connection Diagnosis
Auto Firmware Update

Warranty

2 Years Brand Warranty
