Huawei AP371 WiFi7 Wireless Celling Mount Access Point
Inhouse product
Huawei AP371 WiFi7 Wireless Celling Mount Access Point হুয়াওয়েই এপি ৩৭১ ওয়াইফাই৭ ওয়্যারলেস সিলিং মাউন্ট এক্সেস পয়েন্ট
Huawei eKit AP371 Access Point, AP371(11be indoor,2+2 dual bands, smart antenna, USB, BLE)
Product Specifications
Installation Type • Wall
• Ceiling
• T-Rail
Dimensions without packaging (H x W x D) [mm(in.)] Diameter x depth: 180 mm x 35 mm (7.09 in. x 1.38 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 61 mm x 231 mm x 203 mm (2.40 in. x 9.09 in. x 7.99 in.)
Weight without packaging [kg(lb)] 0.47 kg (1.04 lb)
Weight with packaging [kg(lb)] 0.69 kg (1.52 lb)
Maximum power consumption [W] 13.60 W
Power supply mode • DC adapter
• PoE
Rated input voltage [V] 12 V
Input voltage range [V] DC: 12 V ± 10%
PoE: 802.3at/af
Maximum number of physical ports on the entire device 2.5GE (RJ45) x 1, 100M/1000M/2500 Mbit/s auto-sensing
Long-term operating temperature [°C(°F)] –10°C to +50°C (14°F to 122°F)
(From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.)
Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F)
Long-term operating relative humidity [RH] 5% RH to 95% RH (non-condensing)
Long-term operating altitude [m(ft.)] –60 m to +5000 m (–196.85 ft to +16404.20 ft)
Atmospheric pressure [kPa] 53kPa - 106kPa ETSI 300 019-2-3
Ground Floating ground
Radio number 2
Operating frequency band • 2.4GHz
• 5GHz
MIMO spatial streams Radio 0 (2.4 GHz): 2x2
Radio 1 (5 GHz): 2x2
Wi-Fi standard 2.4 GHz: 802.11b/g/n/ax/be
5 GHz: 802.11a/n/ac/ac Wave 2/ax/be
Radio interface Built-in smart antennas
Antenna gain 2.4 GHz: 4 dBi/chain (peak gain) 1 dBi (combined gain)
5 GHz: 5 dBi/chain (peak gain) 3 dBi (combined gain)
BLE: 4 dBi (peak gain)
Maximum transmit power 2.4 GHz: 20 dBm/chain 23 dBm (combined power)
5 GHz: 20 dBm/chain 23 dBm (combined power)
Signal radio transmit power [dBm] 2.4G: -10 dBm to 20 dBm/chain
5G: -10 dBm to 20 dBm/chain
