VSOL XPON 2.5G ONU V2801Q Dual Mode
Inhouse product
VSOL XPON 2.5G ONU V2801Q Dual Mode ভি সল ২.৫জি অনু ডুয়াল মোড। ইপন ,জীপন সাপোর্ট
Support Bridge Mode & Router Mode
1XPON+2.5GbE ONU
Model: V2801Q
Spec: 1*XPON+1*2.5GbE
VSOL 2.5GE XPON ONT
XPON Dual Mode | Prevent Rogue ONT | Wide Temp Design | Security ONT
HGU/SFU Feature, Flexibly Access Network
Support Bridge Mode & Router Mode
Wide-Working-Temperature Designed
Long time stable connection
|
Dimension |
82mm×82mm×25mm(L×W×H) |
|
Net weight |
0.085Kg |
|
Operating condition |
Operating temp: -10 ~ +55°C Operating humidity: 5 ~ 95% (non-condensing) |
|
Storing condition |
Storing temp: -40 ~ +70°C Storing humidity: 5~ 95% (non-condensing) |
|
Power adapter |
DC 12V, 0.5A, external AC-DC power adaptor |
|
Power supply |
≤4W |
|
Interfaces |
2.5GbE |
|
Indicators |
SYS, LINK/ACT, REG |
|
○ Interface parameter |
|
|
PON interface |
1 XPON port(EPON PX20+ & GPON Class B+) SC single mode, SC/UPC connector TX optical power: 0～+4dBm RX sensitivity: -27dBm Overload optical power: -3dBm(EPON) or -8dBm(GPON) Transmission distance: 20KM Wavelength: TX 1310nm, RX1490nm |
|
LAN interface |
1*2.5GbE, Auto-negotiation RJ45 connectors |
