VSOL Faceplate ONU V2801P XPON
Inhouse product
VSOL Faceplate ONU V2801P XPON
V2801P (1*XPON+1GE Built-in ONT(86 Type)) is a broadband access device specially designed to meet theneedsof fixednetwork operators for FTTH. The panel-type ONU can be easily installed in 86-type electrical boxes on enterprisecampuses.The ONT is based on high-performance chip solutions, supports XPON dual-mode technology (EPON and GPON), andalsosupports Layer 2/Layer 3 functions, providing data service for carrier-grade FTTH applications. In addition, theONTalsosupports the OAM/OMCI protocol, and we can configure or manage various services of the ONT on the VSOL OLT. The ONT has high reliability, is easy to manage and maintain, and has QoS guarantees for various services. It conformstoaseries of international technical standards such as IEEE802.3ah and ITU-T G.984.
Dimension 86mm×86mm×49mm(L×W×H)
Net weight N/A
Operating
condition
Operating temp: -10 ~ +55°C
Operating humidity: 5 ~ 95% (non-condensing)
Storing
condition
Storing temp: -40 ~ +70°C
Storing humidity: 5 ~ 95% (non-condensing)
Power supply 100 ~ 240V AC, 50/60Hz
Interface 1GE
Indicators PWR, PON, LOS, LAN1
